High Precision 400*400mm Metal CNC Engraving Milling Machine

Brief Introduction:

Model: UG-4040
400*400*120mm working area
2.2kw water cooling spindle
PCI NcStudio/DSP offline/Mach 3 controller
Hybrid servo motor driver
Machine precision 0.02mm

INQUIRY NOW

Applications

Mould of Copper, Iron, aluminum, stainless steel. Shoe mould, mobile mould, Red Copper electrode, Building model, name tag, copper stamp.


Features

1.Heavy duty cast Iron as a whole with vibration temper aging treatment ensures no deformation for long time.

2.Cast iron Working table with platform moving type. Durable without deformation enable positioning more preciously .

3.Equipped with  Hiwin Taiwan linear square guide rail diameter 20mm for XYZ-axis, effectively improved the precision.

4.Three axis with precision diameter 20mm lead ball screw transmission ensure the engraving speed and accuracy.

5.High variable speed China Qiancheng 2.2KW water cooling spindle, big torque, longer life, strong cutting ability and continuous work for long time.

6.Leadshine hybrid servo motor and driver H2-758 for XYZA-axis, compared with the stepper motor, ensuring high speed and precision working

7.Rationalized placement of the electronic parts. Optimized heat dissipation effect. Adopt high quality electronic parts, minimizing fault rate.

8.Stainless steel water slot cooling system, ensuring the cooling for the metal & hard materials, improving the processing precision.

9. Optional PCI NcStudio/DSP offline/Mach3 controller

10. With Organ type dust proof for Y-axis.

11. Adorption rigidity coupling, much improving machine precision.

12. Auto tool calibration, more convenient for operation.

13.Auto lubrication system, more  convenient for machine lubricating.

14.With the function of break-point memory ,power failure resuming and automatic home/orgin correction function.Effectively ensure long time working precision.

15.Working Pause, Speed adjust, Working depth adjust at any time while working. Preview the 2D&3D working result With simulation function. Variable Speed is suitable for various materials and industry.

16.Favorable compatibility with various CAM softwares such as Type3/Artcam/Mastercam/Caxa. With intelligent over limit protection function which can stop the mechanical collision due to unproper size given to the design.


Effective working area

400(X)mm*400Y)mm*120(Z)mm

Materials

Heavy duty cast iron machine bed & working table & gantry & Z-axis

Working table

Cast iron with T slot

Moving type

Platform moving

Guide rail

Linear square guide rail ( Hiwin, Taiwan, diameter 20mm)

Transmission

Lead ball screw( diameter 20mm) for XYZ-axis

Driving mode

Hybrid servo motor and driver H2-758 for XYZ-axis( Leadshine)

Spindle motor

2.2kw water cooling (ER20)

Spindle speed

0-24000rpm

Inverter

Fuling

Voltage

AC 220V± 10%, 50/60Hz, single phase

Traveling speed

8000mm/min

Engraving speed

6000mm/min

Machine accuracy

0.02mm

Control system

PCI NcStudio/DSP offline/Mach3

Suitable software

Artcam, Type3, Ucancam V9,etc

Carving Instructions

G code *Uoo *mmg *plt HPGL

Running environment temperature

0-45 ℃

Relative humidity

30%-75%

Cooling system

Stainless steel water slot cooling

Tool calibration

Automatic

Lubrication

Auto

Certificate

CE
